Three phase solar off grid pure sine wave power inverter 1kw 2kw 3kw

Payment Terms:	T/T,WU;Paypal
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: SNT-TPI 3000W

Brand Name: SNAT

Means of Transport: Ocean,Air

We would offer the three phase inverter 1KW to 20KW,for more bigger models,try to contact with our customer serivce.

Three Phase Inverter are used in Industrial or power plant applications, which generally , operated from 220 Volt DC stationary high capacity chargeable batteries power is used to convert DC to 3 Phase 380 or 400VAC, 100 to 200KVA or more . can be use for lighting , power supply for Controls, Emergency shut off vales, Special lube oil pumps, burner ,Gas valve etc..

Performance Specification of Intelligent Inverter:

(1) The inverter is designed by our company independently; it's controlled by CPU, high quality, low cost and the pure sine wave intelligent inverter.

(2) The inverter can be used for any loads (including fan, refrigerator, air-condition, water pump electromotor etc). it has solved the square wave, quasi sinusoid output inverter's disadvantages of doing harm to some loads.

Notice: before you use your equipments, you must confirm it's 1 phase 3 wires (1 is earth) or 3 phases 5 wires (1 is earth). Otherwise it will damage your equipments.

(3) Full automatic intelligent switching.

(4) Output short circuit protection (when the inverter is working on battery mode): when there is short circuit, the inverter will indicate it and the machine will shut down automatically.

(5) Overload protection: when there is overload, the machine will prompt you and protect the inverter from being damaged automatically. Over100%-120%, inverter shuts down about 30s later, over 120%, inverter shuts down at once.

(6) Battery protection: single battery voltage is 10V (limited only in the maintenance free).

(7) Disturbing power protection: surge protection.

(8) City power over-high protection is 480V AC. City power over-low protection is 300V AC or over-high 480VAC.

(9) When the city power R-phase is normal, the battery can charge automatically. can use a DB9 cable connecting with your equipments. It need a 6V to15V DC voltage keeping more then 3 seconds.

Mode	SNT-TPI***	1000W	2000W	3000W
Input	Rated capacity(W)	1000W	2000W	3000W
Input	DC battery input(V)	48VDC
	DC Voltage range	40V-60V
	AC input Power range(VAC)	380V±20%
	Recharge current	15A(Max)	20A(Maximum)
Frequency(Hz)		45-65Hz
Output	AVR voltage range(VAC)	384V±5%
	Transfer time	7MS
	Waveform	Pure sine wave
	Frequency	50Hz/60Hz±0.5%
Protection	overload	Input/output over high or low protecting;low battery protecting;surge and pike-currents protecting; overload protecting 100%-120% 30sec; >120% 100ms; >150%, 50ms output short circiut<150ms
Battery	Battery protection	Automatic self-test, discharge protection, over-chargeing protected, smart management system.
Appearsnce	Machine Size(mm) D×W×H	565230517
	Size(mm) D×W×H	655320620
	Net weight(kg)	35	55	60
	Gross weight(kg)	40	60	70
